Filament Fortaglas

Home > Filament Fortaglas

Filament Fortaglas fabrics provide a wide range of textiles when coupled with various types of coatings, treatments and laminations.

Standard Glass Fabrics (EK)

Service Temperature (°C)

Product Code

Description

Weight (g/m²)

Thickness (mm)

Features and Benefits

Short Term

Continuous*

600

400 (Static)
150 (Flexed)

EKC161
EKC401
EKC622
EKC625

Weavelocked

205-820

0.2-0.75

Weavelock finish Prevents fraying where fabrication is required

350

230

EKS240
EKS409

Silicone coated (single)

240-460

0.2-0.4

The silicone coating offers enhanced durability, flexibility, and resistance to moisture, chemicals, and abrasion.

350

230

EKSS409

Silicone rubber coated (double sided)

520

0.4

The silicone coating offers enhanced durability, flexibility, and resistance to moisture, chemicals, and abrasion on both faces of the fabric.

150

EKNN401

Black Neoprene coated on both sides

850

0.6

FR neoprene provides an impermeable, textured finish that allows molten metal to flow off

150

200

EKA161
EKA401
EKA622
EKA625

Foil aluminised

265-880

0.2-0.8

The aluminium layer acts an impermeable barrier that allows molten metal to flow off while acting as an efficient reflector of radiant heat.

*Temperature resistance under static conditions.

Technical Details

Weavelocked

Short Term (Temp)

600

Continuous (Temp)*

400 (Static)
150 (Flexed)

Product Code

EKC161
EKC401
EKC622
EKC625

Weight (g/m²)

205-820

Thickness (mm)

0.2-0.75

Comments

Weavelock finish Prevents fraying where fabrication is required

Silicone rubber coated (single)

Short Term (Temp)

350

Continuous (Temp)*

230

Product Code

EKS240
EKS409

Weight (g/m²)

240-460

Thickness (mm)

0.2-0.4

Comments

The silicone coating offers enhanced durability, flexibility, and resistance to moisture, chemicals, and abrasion.

Silicone rubber coated (double sided)

Short Term (Temp)

350

Continuous (Temp)*

230

Product Code

EKSS409

Weight (g/m²)

520

Thickness (mm)

0.4

Comments

The silicone coating offers enhanced durability, flexibility, and resistance to moisture, chemicals, and abrasion on both faces of the fabric.

Black Neoprene coated on both sides

Short Term (Temp)

150

Continuous (Temp)*

Product Code

EKNN401

Weight (g/m²)

850

Thickness (mm)

0.6

Comments

FR neoprene provides an impermeable, textured finish that allows molten metal to flow off.

Foil aluminised

Short Term (Temp)

150

Continuous (Temp)*

200

Product Code

EKA161
EKA401
EKA622
EKA625

Weight (g/m²)

265-880

Thickness (mm)

0.2-0.8

Comments

The aluminium layer acts an impermeable barrier that allows molten metal to flow off while acting as an efficient reflector of radiant heat.

*Temperature resistance under static conditions.
